Arctic P12 12cm Pressure Optimised PWM Case Fan, Black, Fluid Dynamic
Arctic P12 12cm Pressure Optimised PWM Case Fan, Black, Fluid Dynamic
Out of stock
Regular price
£4.77
inc. VAT
Couldn't load pickup availability
Product details
- Type Case Fans
- Vendor ARCTIC
- SKU CF120-ARCP12PWM-BLK-B
- Barcode 4895213701389
Share this product with others.
Pressure-optimised 120 mm Fan with PWM
Optimised for Static Pressure
During the development of the new P12 PWM, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the P12 PWM is particularly suitable for use on heatsinks and radiators.
More Efficient Technology
The motor is powered by a Neodym-Iron-Boron-Magnet ring of the newest generation, which allows the new P12 PWM to run much more efficiently than its predecessors. This saves energy and lowers the coil temperature without comprimising the performance.
Maximum Quietness, Minimum Vibration
Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable.
Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor.
Extended Life Span
A 10C lower motor temperature roughly doubles the life span of a fan.
The new ARCTIC motor has a four times longer service life through its low coil temperature.
Consequently, we have extended the warranty to 10 years.
200 to 1800 RPM regulated via PWM
Thanks to the 4-pin connector, the RPM can be regulated in a broad spectrum via PWM.
In this way, noise is kept at a minimum while maximum cooling performance is guaranteed when needed.
0 dB Mode
The P12 PWM is able to switch into silent passive mode when PWM signal is below 5 % due to its new motor. This allows working at your PC in complete silence without any unwanted noise.
High Quality Bearing
Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan.
Two Way Installation
- Push warm air out of the case
- Pull cool air into your case
12V DC
Additional Features
See Overview
Package Type
Retail
Package Weight
0.1730 kg
Warranty
10 Years
0.3 Sone (@ 1800 RPM)
Power
Noise level
Type
Plastic
Fan Connector(s)
4-pin
Installation
Screws
#Hide#LED Lighting
No
Colour
Black
Material
Weight
56.3 CFM / 95.65 m3/h
139 kg
Fan Dimensions
120 x 120 x 25 mm
Fan Controller
PWM
Rotation Speed
200 - 1800 RPM
Fan Bearing
Fluid Dynamic
Air Flow
